Bar-Type TFT LCD Display Module for Automotive Instrument Cluster & Vehicle Application
제품 상세 정보
| 이름 | 바 타입 LCD | 패널 크기 | 19.4" |
|---|---|---|---|
| 해결 | 1920*519 | 명도 | 700(일반) |
| 작동 온도. | 0~50 Ｃ | 활성 영역 | 476.6*129mm |
| 개략 차원 | 503.2*156.2*14.5mm | 인터페이스 | LVDS(2채널, 8비트) |
| 강조하다 | Bar-Type TFT LCD automotive display,Vehicle instrument cluster LCD module,Bar-Type LCD for car dashboard |
||
제품 설명
Bar-Type TFT LCD Display Module for Automotive Instrument Cluster & Vehicle Application
High-performance bar-type TFT LCD display module specifically designed for automotive instrument clusters and vehicle applications, offering exceptional reliability and customization options.
Product Advantages
- Advanced manufacturing with 3 cutting machines and 2 production lines supporting lengths up to 1.7m (75 inch cutting)
- Precision cutting technology ensuring high yield and dimensional accuracy
- High reliability with identical features to original equipment panels
- Superior anti-vibration performance for automotive environments
- Customizable brightness ranging from 500-2500 nits
- Extended lifespan: 50,000 hours typical, up to 80,000 hours maximum
Product Applications
- Commercial signage: Advertising displays and price shelves
- Public transportation: Bus, metro, and light rail billboards
- Guidance boards and elevator advertising displays
- Financial services: Bank call notice boards
- Identification cards and bus stop/station displays
- Taxi, bus, and subway advertising boards
Technical Specifications
Model: LCMA-RX0194TA01-C070
| Brand | Rogin |
|---|---|
| Series | Cutting (Bar) Type LCD Display |
| Panel Size | 19.4 inch |
| Brightness | 700 nits (Support customized) |
| Resolution | 1920 × 519 |
| Active Area | 476.6 × 129 mm |
| Overall Size | 503.2 × 156.2 × 14.5 mm |
| Interface Definition | LVDS (2 ch, 8-bit) |
| Backlight Type | WLED |
| Contrast Ratio | 3000:1 |
| Touch Panel | Without |
| Operating Temperature | 0~50 ℃ |
